JEE Main 2017PhysicsMotion In One DimensionEasyMCQ

JEE Main 2017 — Motion In One Dimension Question with Solution

JEE Main 2017 (08 Apr Online)

Question

Which graph corresponds to an object moving with a constant negative acceleration and a positive velocity?

Choose an option

Show full solutionCorrect option: C
Correct answer
C

Step-by-step explanation

Let acceleration be a.
Given that a=-C
We know that, a=vdvdx=-C
vdv=-Cdx

Integrating the above equation,
v22=-Cx+k.

Thus, the velocity-distance graph is

The distance cover by the object is x= -v22C+kC.

Thus, with the increase in distance, velocity decreases.

Now, a=-C=dvdt

⇒dv=-Cdt⇒v=-Ct+u , straight line
